SY LED6 Current or Voltage Input Active Digital Panel Meters

SY LED6 Current or Voltage Input Active Digital Panel Meters

15.35 - 18.30 USD ($)/Piece

Product Details:

  • Input 0-5V, 0-10V, 0-75mV, 0-2.5V, 0-±5V, 0-±10V, 0-±100mV, 0-1mA, 0-10mA, 0-20mA, 4-20mA, 0-±1mA, 0-±10mA, 0-±20mA
  • Power Supply 5V, 12V, 15V, 24VDC
  • Output 4mA display range: -1999~9999, 20mA dispaly range: -1999~9999
  • Product Type Digital Panel Meters
  • Dimension(L*W*H) 76.5*39.2 Millimeter (mm)
  • Supply Ability : 50000 Piece Per Month
  • Click to view more
X

Price And Quantity

  • 15.35 - 18.30 USD ($)/Piece
  • 1 Piece

Product Specifications

  • 4mA display range: -1999~9999, 20mA dispaly range: -1999~9999
  • 0-5V, 0-10V, 0-75mV, 0-2.5V, 0-±5V, 0-±10V, 0-±100mV, 0-1mA, 0-10mA, 0-20mA, 4-20mA, 0-±1mA, 0-±10mA, 0-±20mA
  • Digital Panel Meters
  • 5V, 12V, 15V, 24VDC
  • 76.5*39.2 Millimeter (mm)

Trade Information

  • Shenzhen
  • Paypal, Telegraphic Transfer (T/T)
  • 50000 Piece Per Month
  • 3 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia

Product Description

Technical Specification:

1. Power supply: DC regulated power supply, rippl less than 5mV, 5V, 12V, 15V, 24V or other value.

Input signal is 4~20mA, no external power supply is required; it operates in loop powered mode

2. Input signal: 0~5V, 0~10V, 1~5V, 0~±200mV, 0~20mA, 4~20mA, other customized input.

3. Operating temperature range: -40 to +85 degree

4. Relative humidity: 20%~90%RH

5. Shock vibration: in compliance with industrial ministry environment test II meters requirements.

6. Panel display mode: Red LED display, font height 14.2mm (0.56in), decimal point is settable.

7. Average sampling rate: 2.5times/second.

8. Digit display setting range:

(1) 4mA: -1999~9999

(2) 20mA: -1999~9999

9. Polarity conversion: lower than the ZERO value, it display "--", higher than the ZERO value, it does not display polarity symbol.

10. Accuracy: full range linearity error ±2 digits (relative to 2000)

11. Temperature influence error: less than 80PPM/degree

12. Exceed the measuring range displays "oHH" or "oLL"

13. Net weight: 35g. External dimension: 79 x 43 x 23mm. Panel cut-out dimension: 76.5 x 39.2 (+0.1 mm)


Features:

1. Low cost module design, easy to be embedded into other meters and instruments.

2. High measuring accuracy, 4 byte display, ±2 digit.

3. LED display panel, can be used in different lighting conditions.

4. Small size: 79x43x23mm

5. Cut-out size: 76.5 x 39.2 (+0.1mm) Weight: 40g

6. Industrial grade temperature range: -40 to +85 degree, high reliability.


Application:

1. Sensor, transmitter operation status display.

2. Industrial equipment operating monitoring, measurement and remote controlling.

3. Oil, chemistry, environment protection, mining system monitoring.

4. Temperature, pressure, flow, level signal monitoring and display.

5. PLC, DCS system operation data acquisition and display.

6. Meters & instrument, medical devices, industrial controlling device design.


Introduction:

SunYuan SY LED6 Digit display meter is a current voltage meter with wiring socket used in transmitter measuring circuit. It can display current voltage signal (0~5V, 0~10V, 1~5V, 0~±200mV, 0~20mA, 4~20mA, etc signal) in linearity and in decimal base based on the pre-setting range. That LED display meter operates in equal and stable brightness and its LED panel is driven by constant

current. It has reverse polarity and over current protection circuit, and widely used in temperature, pressure, flow, level signal controlling and monitoring system in industrial site, oil industry, environment monitoring, mining industry, etc. Usually, the temperature sensor, pressure sensor, flow sensor, level sensor signal are converted into standard voltage current signal, and then connect it into that LED meter to display the sensor signal to make it easy to monitoring and controlling. There are two types of connection: 2-wire passive connection, it is applied for 4-20ma signal, no external power supply required. 3-wire active connection, it is applied for 0-5V, 0-10V, 1-5V, 0-20mA, etc signal, external power supply required, the power supply can be 5V, 12V, 15V, 24V. There is 2 buttons on the backside of the panel meter; it is used to set zero, span, decimal points, alarm, delay, etc parameters.The input signal and the digits displayed are in linearity. For example, input signals 0-10V, the panel display 0-1000, the linear relationship: 0V displays 0, 5V displays 500, 10V displays 1000. If input is 4-20mA current signal, the LED panel displays 40-200, the linear relationship is 4mA displays 40, 12mA displays 120, 20mA displays 200. The max. display range is 9999, the min. display range is -1999.

SY LED6 LED Display meter has alarm function and 2-channel isolation switching quantity output, and can display, control, alarm output signal synchronously. That alarm function can be realized through programming. There are 2 wielding pad preset for user, if alarm function required, user needs to add 2 pieces of PC452 optical coupler. That LED meter has two alarm points, and positive, negative alarm direction setting. The alarm points is set based on the digits displayed in the LED panel, when it alarms, the last decimal point in LED panel is flashing, the alarm signal data output can drive the alarm unit of optical coupler. SY LED6 external shell is ABS plastic shell, external dimension is 72x36mm, height or thickness is 23mm.


Click below link to check the data sheet:

https://drive.google.com/file/d/1IjzoRzUb4f6Q9JQ_38itFp2FySeRiP01/view
