SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators

SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators

Product Details:

  • Output 4mA display range: -1999~9999, 20mA dispaly range: -1999~9999
  • Input 4-20mA
  • Power Supply Loop powered
  • Product Type Digital Panel Meters
13.00 - 16.00 USD ($)/Piece

SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators Price And Quantity

  • 13.00 - 16.00 USD ($)/Piece
  • 1 Piece

SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators Product Specifications

  • 4mA display range: -1999~9999, 20mA dispaly range: -1999~9999
  • Digital Panel Meters
  • Loop powered
  • 4-20mA

SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators Trade Information

  • Shenzhen
  • Telegraphic Transfer (T/T) Paypal
  • 50000 Piece Per Month
  • 3 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Australia North America South America Eastern Europe Western Europe Middle East Africa Central America Asia

Product Description

SY LED3 Two Wire Loop Powered 4-20mA Digital Panel Indicators

Technical Parameters:

1. Using conditions

(1) Current: Rated range 3~22mA

Limited range: less than 100 mA

(2) Temperature range: Rated range: -20 to 60 degree

Limited range: -40 to 70 degree

(3) Relative humidity 20%~90%RH

(4) Shock & Vibration: meet industrial electronics environmental test II meters' requirements.

2. Panel display method:

Black LED digits and decimal display, digits height 10.1mm (0.40inch)

3. Four-digit Display Meter Setting Range:

(1) 4mA: -1999~9999

(2) 20mA: -1999~9999

4. Voltage drop:

Voltage drop less than 3.2V, with over-current protection.

5. Polarity conversion: If lower than the zero limit, the meter display "-", if higher than the zero limit, no polarity mark display.

6. Accuracy: linearity offset 2 digits (to 2000 rated value).

7. Temperature error:less than 50PPMdegree

8. Over-range display: "oHH" or "oLL".

9. External Dimension: 47.6/38.016.6mm Flame retardant housing shell.

10. Panel perforation dimension: 33x20.5 +0.2mm


1. Low cost modular design, easy to install in use

2. 2-wire passive operation mode, no auxiliary power.

3. High measuring accuracy, 4-digit display, 2 digits

4. LED display panel, adapt to different lightness requirements.

5. Small size, dimension 47.6/38.016.6mm (H.:16.6mm)

6. Industrial operating temp.: -25 to 70 degree, high reliability.


1. Sensor, transmitter operating status display.

2. Industrial equipment monitoring or remote control

3. Oil, chemical, environmental system monitoring

4. Temperature, pressure, flow, level signal monitoring and display.

5. PLC, DCS system operation data acquisition and display

6. Developing meters & instruments, medical devices, industrial equipment.


SunYuan SY LED3 4-Digit 2-wire Passive Intelligent 4-20mA Current LED Display Meter input is passive signal, output 2 lines can be connected to the transmitter 4-20mA loop in serial. It can display decimal number correspondingly based on the settings through 4-20mA analog signal in the loop. SY LED3 series Display Meter is designed on the base of 2-wire passive mode; it measures the electric signal which can be used as the input signal and the operating power supply of the display meter. The meter operates without power supply, low cost, high precision, small size, so it is very convenience to use. The traditional analog display meter uses potentiometer to do adjust parameters, it is not convenience and very easy to be effected by temperatures. Compared with traditional analog display meter, the LED display meter is set by 2 buttons and controlled by CPU, the zero, span, decimal, alarm, delay time, etc parameters can be set by users, it is much more flexible and convenient in use. That display meter has use LED display board and operates in continuous voltage, in the 4-20mA measuring range, the display digits are in equal and stable brightness. It has anti-reverse connection, over-current protection and is widely applied in industrial site, oil, environment monitor, temperature, pressure, flow, level measuring, etc site and fields. In the actual applications, the LED display meter converts temperature, pressure, flow, level, etc physical quantity into 4-20ma signal, then connect with SY LED3 display meter, it displays the temperature, pressure, flow, level, etc physical quantity to provide convenience for user to monitor and control the industrial site.

SYLED3 Display Meter is used to measure 4-20mA DC current signal, it does not need power supply and get power from 4-20ma current loop. The digits displayed are not the actual current value, it is the preset value of 4mA, 20mA, and displays the current valued measured based on the preset value in linearity method. E.g.: 4mA is set to 0, 20mA is set to 8000, then if input is 8mA, the meter displays 2000, input is 12mA, the meter displays 4000. If 4mA is set to 1000, 20mA is set to -1000, when input is 12mA, the meter displays 0, input is 16mA, the meter displays -500. The max. display range is 9999, that is four digits, min. Display range is -1999.

SY LED3 Digit Display Meter has alarm function and 2-channel isolated switch quantity output to realize timely display, controlling and alarm. The alarm function is realized by programming, and there are 2 pieces of PC452 land pad is reserved for customer use when alarm function is required. The display meter has 2 alarm points which can be set in up and down directions. The alarm target of the alarm point is the digit displayed, when there is alarm, the last decimal of the LED Meter is flashing, and the alarm signal is output through terminal which can drive the Optocoupler.

SY LED3 Dimension: 47.6/38.016.6mm, Height:16.6mm, the external shell is made of flame-retardant plastic. The meter is mainly used to display the sensors or transmitter or controlling meters signals. The display meter panel perforation dimension: 33x20.5 +0.2mm
