Product Description

SY AD U(A)-RJ45 Series Multi-Channels Analog Signal to RJ45 Ethernet A/D Converters

Features:

1. Directly convert 4-20mA and other analog data into communication digital data for Ethernet and Can bus.

2. Support 10M Ethernet RJ45 interface, support Modbus TCP communication protocol.

3. Support RS 485/RS 232 serial ports extended, support Modbus RTU protocol.

4. Measuring precision is more than 0.05%, do calibration on the precision of modules by computer is available.

5. 8-channel analog input with common ground, 3000VDC isolation between I/O terminal and the system.

6. Wide range auxiliary power supply wide range: 8~50VDC

7. Unique external form, high reliability, programmable, DIN Rail 35 standard installation.

8. User can programme to set address, baud rate, etc for the modules.

Applications:

1. Monitoring, measuring and remotely controlling the industrial field through local area network.

2. Applied in the industrial intelligent system for Ethernet, RS232/485 can bus

3. Gathering 0-10V/4-20mA signal and converting into Ethernet RJ45 output.

4. Sensor signal A/D conversion, network control and long distance transmission.

5. Ethernet multi-channel analog data acquisition, monitoring and long distance transmission.

6. Meters and instruments data acquisition and recording

7. Monitoring operating data from electric equipments,transportation and other equipments system.

8. Achieve the network operation in Environment protection equipments, security, medical equipments and other equipments.

Introduction:

SUNYUAN SY AD 08-RJ45 series products achieve the analog data acquisition between sensor and host machine to detect analog signals or monitor remote equipments. Through setting the software, it can be applied in various types of sensor including: analog signal input, analog signal output and digital signal signal input/output. SY AD08-RJ45 series products can be applied in RS232/485 bus and RJ45 port in Ethernet industrial automatical control system, 4-20mA/0-10V analog measuring, monitoring and controlling, 0-1mA/0-30mV/small signal measuring, industrial site signal isolation and long distance transmission,etc.

The products have the following functions: power supply isolation, input and output signal isolation, linearization, A/D conversion and RS485 serial or Ethernet communication. Each serial port can connect at most 256 pieces of SYAD08-RJ45 series modules, the communication methods adopt serial port ASCII character communication protocol or Modbus RTU protocol and Ethernet Modbus TCP protocol, its command set is compatible with ADAM modules, the configuration parameter can be set by users, and the module can operate well in the same can bus with the controlling modules from other companies to make it easy to programme through computer.

SY AD08-RJ45 module is an intelligent monitoring and controlling system based on MCU, all the IP address, interface number, calibration value, ID address, baud rate, data format, states and other configuration information which set by user are stored in the nonvolatile storage device.

SY AC08-RJ45 series products are designed and developed by following industrial standards, which can withstand 3000VDC isolation power. The signal input/output are isolated, the modules have high anti-interference performance, high reliability. Operating temperature range: - 45 to +85 degree.
